| Specification VMX21 | |
| Kvs direct way | 2.5 |
| Threaded connection | G 1/2" M |
| Kvs angle way | 1.6 |
| Close off (bar) | 2.5 |
| Thumb | File Name | File Size | Action |
 |
MICRA_DBL199e.pdf | 379.29KB |
Series V.X.- PN16 brass valve bodies
- Tight close-off both on direct and angle way
- PPS plug with double EPDM o-ring - Fluid: water and water+glycol 30% max.
- Temperature 5 to 95 °C - Stroke 2.5 mm
- Threaded connections for conic and flat tight - Motorised by MVX-MVR.
| servomotoare | |
| Kvs direct way | 2.5 |
| Threaded connection | G 1/2" M |
| Kvs angle way | 1.6 |
| Close off (bar) | 2.5 |
3-way Fan-coil Valves VMX21
- Product Code: Controlli VMX21
- Availability: Ask
- Weight: 1.00 kg
Order by phone or request additional info at +40 728 628 394
