| Specification MVB52 | |
| Supply (V) | 24 |
| Force (N) | 450 |
| Action | Vdc/ current proportional control. Ranges: 6 to 9, 4 to 7, 8 to 11, 0 to 10, 2 to 10, 1 to 5 Vdc, 4 to 20 mA. Default setting: 0 to 10Vdc |
| Thumb | File Name | File Size | Action |
 |
MVB_DBL005e.pdf | 148KB |
Series MVB
- Bidirectional motor for V.B threaded ½” to 2” and flanged 15 to 50 mm valve
bodies
- Supplied with linkage for mounting on 2T-3T and V.B-V.BF valve bodies
- IP50 protection.
| servomotoare | |
| Supply (V) | 24 |
| Force (N) | 450 |
| Action | Vdc/ current proportional control. Ranges: 6 to 9, 4 to 7, 8 to 11, 0 to 10, 2 to 10, 1 to 5 Vdc, 4 to 20 mA. Default setting: 0 to 10Vdc |
Electro-thermal actuator MVB52
- Product Code: Controlli MVB52
- Availability: Ask
- Weight: 1.00 kg
Order by phone or request additional info at +40 728 628 394
